Page 64 - Picture No. Page 65 - Picture No. Page 66 - Picture No. Page 67 - Picture No. Table of Contents. Page 4 Automatic boiler for wood pellets 8. This product may only be operated by adult persons, duly acquainted with the way the product is controlled and duly acquainted also with these Instructions.
Its shape is adapted in such a way so that combustion products are cooled down efficiently at individual levels of power output, which is, moreover, assisted by a system of turbulators. Page 9: Control Unit Automatic boiler for wood pellets 3. This control system enables automatic boiler operation through the control and regulation features thermostats, sensors, etc. It also enables Diagnostics mode of control, which can be used for instance for boiler commissioning. The HZS is a simple component that is used to control automated processes in a heating system.
Page Picture No. Picture No. Page Technical Base Data Automatic boiler for wood pellets 3. Process diagnosis as well as operating and monitoring automated procedures is simplified using this terminal.
A touch screen serves as the input medium for process data and parameters. Page 14 Automatic boiler for wood pellets Display Type 5. Page Burner Heating Chamber Incl. Page Ceramic Parts Feeder F1 set comprises of: 4. It is painted with durable paint applied with the powder painting technology KOMAXIT , which is highly resistant to outside conditions and ensures long-term perfect look of the product.
How to Add " Print to PDF " in Printer List Options - 100% Working
Page Cleaning System Automatic boiler for wood pellets 3. It enables long-term service-free operation even when using fuel with high ash content.
It is attached to the boiler with a detent lever. During boiler operation the lever must be in the lower position and the connecting piping between the boiler and the ash receiver must be tight.
Page Standard Accessories Automatic boiler for wood pellets 3.
Boiler must be placed on horizontal non-flammable material, which overlaps min. Page Fire Regulations Automatic boiler for wood pellets Recommended draught of chimney has to be within the range specified by the manufacturer in connection with the installed power output of the boiler.
Page Putting The Products Into Operation Recommended connection of the boiler to the heating system — see section picture. Steps: Chyba!
Connect the particular appliances according with connection diagram. During connecting the equipment must be shut down with the main switch or disconnected from power supply by pulling the electric cord from the outlet.
Page Burner Grate Cleaning Automatic boiler for wood pellets 6. Always perform cleaning, when a continuous layer of ash exceeds 4cm.
Kp 02 irigasi pdf printer
Clean the burner grate with jets simply by moving a scraper along the burner grate area. Page Annual Audit Automatic boiler for wood pellets 6. This audit is necessary in order to prevent from possible non-standard conditions in the next year of operation of the equipment. If the annual audit is not performed as per the below mentioned programme, this may be considered by the manufacturer to be the reason for rejection of guarantee conditions in the second year of use.
Ponast KP 82S Service And Operation Manual
Page 36 Automatic boiler for wood pellets if automatic ignition is installed on the burner, dismantle both spirals and remove all impurities from the air box of the burner through the installation apertures.
Cleaning of burning chamber In order to prevent from increased dustiness, we recommend placing the lid of the boiler body on the boiler for this time. Page Main Menu Automatic boiler for wood pellets 8. Page Menu Users Settings Automatic boiler for wood pellets 8. In the end confirm: If is password right — Page 43 Automatic boiler for wood pellets Cleaning an ash removing Time window setting Skin In the end confirm: If is password right — button change on green colour 8.
In the end confirm: If is password right — button change on green colour Note: If you have empty feeders — Page 46 Automatic boiler for wood pellets Actual values Configuration Page 47 Automatic boiler for wood pellets Parameters The setting value of parameters is important for combustion quality, correct function and safety.
The producer saves changes of parameters by password. Is prohibited to make unqualified changes. Actual setting depend on the type of boiler! Producer and qualified service can make changes only!
Next page Page 48 Automatic boiler for wood pellets Next page: Previous page Maximum boiler temperature Temperatures Minimum exhaust temperature for heating Maximum exhaust temperature Temperature for activate pump Temperature for activate bypass pump Button for activate electric heating Page 49 Automatic boiler for wood pellets Button for activate electric ignition.
Page 52 Automatic boiler for wood pellets Cleaning, Ash removing Time window setting Page Menu - Heating Circuits Automatic boiler for wood pellets 8.
Page Tank Automatic boiler for wood pellets After confirmation: 8. Page 56 Automatic boiler for wood pellets Function for settings of parameters Function for manual control of pump Page Sanitary Water Automatic boiler for wood pellets 8. Page 58 Automatic boiler for wood pellets Page Heating Circuit Automatic boiler for wood pellets 8. Page 60 Automatic boiler for wood pellets Page 61 Automatic boiler for wood pellets Page Guarantee And Liability For Defects The user can use the application unchanged as well as in particular modification to the best solution of heating system.
This is primary responsibility of the designer and implementer of the heating system - which is why the Ponast company cannot take over the guarantee for the functionality of a particular solution of heating system.
Page Technical Data This manual is also suitable for: Kp 52s Kp 22s Kp 12s Kp 62s. Comments to this Manuals Your Name:. Enter text from picture:.
