Page 85 - Troubleshooting Page 86 - The printer sounds like it is printing, Table of Contents. Page 2: Copyrights And Trademarks Epson is not responsible for any use of this information as applied to other printers. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or excluding the U.
Page 4 Replacing Paper Page 5 Contacting Epson Support Also be sure to follow all warnings and instructions marked on the printer.
When choosing a location for this product Place this product on a flat, stable surface that is larger than this product. This product will not operate properly if it is tilted or at an angle. Use of another cord may result in fire or electric shock. Do not use a damaged or frayed power cord.
Warnings, Cautions, Important and Notes Warnings must be followed to avoid serious bodily injury.
Warning: Caution: Cautions must be followed to avoid damage to this product or bodily injury. Important: Important must be followed to avoid damage to this product.
Maintenance box covers Open these covers when replacing the maintenance box. Casters There are two casters on each leg.
The casters are normally kept locked once the printer is in place. Page 10 Ink tanks Hold ink used for printing. Side cover Open the side cover to remove the slider for chip unit replacement.
Always close the side cover securely after inserting the slider. AC inlet Connect the supplied power cable here. Page Slider chip Holder Adapter guides Guides for attaching roll paper.
Move the roll along these guides to attach it to the adapter holder.
Epson surecolor f6070 pdf viewer
Roll lock lever A lever that locks roll paper in place after the roll is attached to the adapter holder. Adapter holder The roll paper adapter is placed in this holder after the roll paper is attached.
Adapter lock lever Lift to unlock, lower to lock. Unlock when attaching roll paper to the adapter, lock once the roll is attached. Flashing : The printer is receiving data or cleaning the print head or performing other operations in the course of being shut down. Page 14 Menu button Displays the menu for the tab currently selected in the display.
O If printing is not currently in progress and the printer is loaded with roll paper, you can feed paper ahead by pressing first this button and then the d button.
Use the l r buttons to select a tab. Information on the selected tab appears in the info display area. The Info Display Area The print queues tab info display area shows the name of the current print job. Page 17 The chip unit requires replacement. Replace the chip unit with one from a new ink pack. As it gets closer to time to replace the chip unit, a icon will begin to flash. Ink color codes Black Yellow Magenta Cyan The Maintenance Tab The maintenance tab shows the status of the maintenance boxes and is used to display the Maintenance menu.
Page Features Features The main features of this printer are described below. Realizing High Productivity High-speed printing The speed of the print head and paper feed have been increased for faster printing. The printer is equipped with a high-speed rotary cutter for quick cutting, significantly increasing productivity.
Page Notes On Usage And Storage Easy maintenance Roll paper and all replacements, including ink refills, maintenance boxes, and cutter, are installed from the front, allowing the printer to be placed against a wall. The printer does not have to be moved to allow rear access.
Search By Product Name
Notes on Usage and Storage Installation Space Make sure that you secure the following space, clear of any other objects, so that paper Even when the conditions above are met, you may not be able to print properly if the environmental conditions are not suitable for the paper.
Page Notes On Handling Ink Packs And Ink Tanks If you will not be using the printer for more than 2 weeks, maintenance must be performed by a service engineer before and after this period.
This maintenance work will be charged. Note that even if proper maintenance has been done before leaving the printer for a long time, repair may be necessary when doing maintenance for reusing the printer, depending on the period and conditions of storage.
Page Notes On Handling Paper To ensure print quality, use all the ink in the ink pack before one of the following whichever comes first : The date printed on the ink pack 25 days from the day that the ink tank was refilled from the ink pack If the ink pack has been stored in a cold location for a long period of time, keep at room temperature for at least 4 hours before using.
Page Using The Supplied Software For information about these applications, see the on-line help for the application in question. Note: The included software CD does not contain any printer drivers. A software RIP is required to print.
Important: You must log in as an Administrator. Enter the Administrator password when prompted and then proceed with the remainder of the operation. Page 26 4.
Select the target printer icon, and then click OK. Follow the on-screen instructions to continue. When the delete confirmation message appears, click Yes. Restart the computer if you are reinstalling the Epson communications driver. Important: Insert the paper just before printing.
Epson SureColor F6070
The roller may leave an impression on paper that is left in the printer. Page 28 3. Place roll paper on the roll rest on top of the printer. Size the two supplied roll paper adapters to the roll core. Raise the adapter lock lever to release the lock on each of the two roll paper adapters.
Basic Operations Page 29 6. Press the adapters in until they are fully inserted in the roll, with no gaps.
Lower the lock levers to lock the adapters in place. Slide the roll paper all the way to the right. Following the adapter guides, slide the roll slowly back. Page 30 9. Press the button on the control panel. Confirm that Roll Paper is highlighted in the display and press the OK button. Insert the end of the roll paper in the paper slot and pull it through.
Make sure that the paper is free of slack and that the end is not folded. Page Cutting Roll Paper Lower the roll lock lever. Following the on-screen instructions, press the OK button. The paper will be fed into the printer. Check the media type. The printer will display the Paper Type and Roll Paper Remaining settings for the paper currently selected with the printer.
Page Setting Method Manual cut: Press the button to cut the paper using the built-in cutter. A cutline is printed for manual cutting and can be used as a guide when cutting paper using the built-in cutter.
PLOTER EPSON SURECOLOR F6070
Note: It may take a while to cut the roll paper. Some of the roll paper may not be cut using the built-in cutter. Page Removing Roll Paper Cutting paper manually using the built-in cutter 1. Press the button. Page 34 Buttons that are used in the following settings: 1.
Epson SureColor F6070 User Manual
Confirm that the printer is ready and press the button. Note: To calculate Roll Paper Remaining, you must enter the length of the roll paper when the roll paper is installed. Page 35 4. Raise the roll lock lever. Holding the paper by the roll adapters, move the roll to the roll rest.
Lift the adapter lock levers to release the roll paper adapters. Remove the roll paper adapters.
