Page Illustrated Parts Catalog Illustrated parts catalog Serial number label location When ordering parts or requesting information, the serial number label, located inside the battery bay, provides important information that you may need when contacting technical support. NOTE: Serial number label location, format, and color vary on select models. Item Description Spare part number Display Hinge Kit, includes: 1a Left and right hinge covers 1b Left and right hinge caps Page Mass Storage Devices 7.

Page 39 Spare part number Description Keyboard, Charcoal, for use only in Portugal includes cable Keyboard, Charcoal, for use only in Turkey includes cable Keyboard, Charcoal, for use only in Latin America includes cable Keyboard, Charcoal, for use only in Saudi Arabia includes cable Keyboard, Charcoal, for use only in Hungary includes cable Page 40 Spare part number Description Top cover, Crimson Red includes TouchPad board and bracket Heat sink includes replacement thermal material Hard Drive Hardware Kit TouchPad button board includes cables Plastics Kit includes left and right rear corner covers Page 45 Spare part number Description Display assembly, Improper cable placement can damage the device.

Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Circuitry design and structure determine the degree of sensitivity.

HP Customer Support - Software and Driver Downloads

Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. Page Equipment Guidelines Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

Hp mini 210 4150nr manual

To provide proper ground, wear a strap snugly against the skin at all times. Page Component Replacement Procedures Component replacement procedures This chapter provides removal and replacement procedures.

There are as many as 33 screws, in 3 different sizes, that must be removed, replaced, or loosened when servicing the computer.

Hp mini 210 4150nr manual

Make special note of each screw size and location during removal and replacement. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Page Wlan Module Replace the service door: Replace the service door and slide it toward the back of the computer.

Insert the back edge of the battery into the battery bay and then pivot the battery downward.

Hp mini 210 4150nr manual

Press down on the battery until the latch locks. Reverse this procedure to install a WLAN module. Page Memory Module Remove the battery see Battery on page Remove the service door see Service door on page Remove the Phillips M2. Page Rtc Battery Remove the battery see Battery on page Remove the memory module: Pull away the retention clip 1 on each side of the memory module to release the module.

Cours danglais facile pdf editor

The memory module 2 tilts up. Page Hard Drive Remove the battery see Battery on page Remove the RTC battery: Lift the edge 1 of the battery from the system board.

Hp mini 210 4150nr manual

Remove the RTC battery 2 from the socket on the system board. Reverse this procedure to install the RTC battery.

Page 59 Before removing the hard drive, follow these steps: Shut down the computer.

HP Mini 210-4150nr PC Manuals

Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer. Page 60 Remove the hard drive bracket 3. Reverse this procedure to reassemble and install the hard drive.

Hp mini 210 4150nr manual

Chapter 4 Removal and replacement procedures Page Keyboard Keyboard NOTE: For the complete list of available keyboards, see Computer major components on page Before removing the keyboard, follow these steps: Shut down the computer.

Page 62 Position the computer on its side. Using a screwdriver or a similar tool, push firmly through the bottom of the base enclosure 1 to release the keyboard 2. NOTE: Extra effort may be required to release the keyboard. Position the computer right-side up. Rotate the keyboard over onto the palm rest 1.

Iso 27001 overview pdf merge

Page 63 Lift the keyboard 4 straight up to remove it from the computer. Reverse this procedure to install the keyboard. Component replacement procedures Page 65 Remove the five Phillips M2.

HP Mini 210-4150nr PC

Position the computer upside down, with the front toward you. The ZIF cable is secured with double-sided adhesive tape. Remove the five Phillips M2.

Hp mini 210 4150nr manual

Page 66 Lift the front edge 1 of the top cover until it disengages from the base enclosure, and then remove the top cover 2 by lifting it straight up. Reverse this procedure to install the top cover. Page Speakers Speakers Description Spare part number Speakers include cables Before removing the speakers, follow these steps: Shut down the computer.

Display assembly NOTE: For a complete list of display assemblies, refer to Display components on page Before removing the display assembly, follow these steps: Shut down the computer. Page 70 Remove the two Phillips M2. Remove the WLAN antenna cables 1 from the routing channel. Disconnect the display panel cable 2 from the system board. Carefully lift the base enclosure away from the display assembly 3.

Reverse this procedure to reassemble and install the display assembly. Page 72 Remove the display assembly components: Remove the hinge covers from the hinges. Remove the two Phillips M2.

Upgrade memory HP Mini Beats 210 - Model 210-4150NR Netbook - Netbook 10.1 inch

Remove the display hinges 4. Page 73 To remove the display bezel, loosen the top of the bezel 1 , loosen the left and right sides of the bezel 2 , loosen the bottom of the bezel 3 , and then lift the bezel from the display 4.

Software and drivers for

To remove the webcam module, unplug the cable from the webcam module 1 , remove the silver Phillips M2. Page 74 To remove the display panel from the display enclosure, remove the 4 Phillips M2.

Page 76 Spare part number Intel Atom N single-core, 1. Page 77 Tilt the system board away from the base enclosure 3.
